Product Detail
Share to:

SC-GH250E Ultrasonic Gravure Portable Cleaner

Enables to clean cylinder directly in the printing machine
Energy saving design
Transportable to be used in various places inside your factory
Product details

SC - GH250E


Manual type, can online cleaning

Energy conservation and emissions reduction

Easy to move, can be used in various field


Easy to clean at anytime

A roll can be cleaned to remain equipped.

Touch cleaning head to cylinder directly.

No brushing necessary.

Saving cleaning time

No need to remove and install a roll.

Great contribution to better productivity.

Economical and Compact

Only needsmall power and compressed air.

Space saving & easy to move



SC-GH250E'sFeatures


·       For rolls that are difficult to clean by problem ofremoving
and mounting.

·       The roll can be cleaned to remain equipped. Touch the
cleaning head to the cylinder directly.
No need to rub with brush.

·       Modest consumption of power and compressed air.

·       Compact and movable.


Extending the service life of theversion of the roll

To clean deep outlets, therealization of adhesive, printing ink, such as amount of stabilization.





Specifications


Product model

SC-GH250E

Oad ・ weight

Cleaning head
   W: 305 x D: 151 x H: 151 mm
 Cable length 5 m Approx. 3 kg
(Cleaning area W: 250 x H: 75 mm)
   Control box
   W: 320 x D: 640x H: 810 mm Approx. 35 kg

Gas supply air

AC 110, 120,   220, 240 V 50/60 Hz
   300 VA

ultrasonic

40 kHz, 150 W

Gas supply air

0.2 MPa, 100   NL/min

Configurable gravure cylinder size

Less than φ300

规格的更新不另行通知
